Model No.: PS-ULV-003H Model No.: PS-ULV-004H
Feature:
1. Producing nearly invisible droplets, better penetration, quickly diffusibility.
2. Could adjust the flow rate continuously, in order to get different diameter of droplets.
3. High power, high speed aerosol droplets, high-work-efficiency, economical.
4. Solution tank is marked with capacity scale, so it is helpful when you adding precise
volume of solution.
5. Compact size, the solution tank could be disassemble, ease of adding solution.
6. Could choose the solution tank with its capacity of 4L or 6L.
7. With an adjustable output of 0~36L per hour, could adjust the flow rate to applying for ultra-low-volume or low-volume spraying, this versatile unit gives you the power to handle both large and small area, wherever the ULV aerosol generator is needed.
8. It is ideal for increasing humidity and dispensing sanitizers, the durable plastic body is made from rugged chemical resistant polyethylene for years of trouble free operation. Both oil and water based solutions can be misted through the non-clog nozzle.
9. PS-ULV-004H, a model like PS-ULV-003H, but it has a flexible hose with handle on nozzle permits spraying into normally inaccessible and hard to reach area such as under/between kitchen cabinets, under carpets and above ceilings. The Flex Hose unit is ideal for general pest control and duct work that requires disinfectant or duct sealant applications.
Field of application: All of our ULV aerosol generators feature the full benefit of ultra low volume method of dispensing water or oil-based chemical formulations.
It is capable of dispensing pesticides, deodorants, fungicides, disinfectants, miticides, Poultry Vaccines,
odor neutralizers, etc. It had been widely used by our customers in a variety of indoor/outdoor
applications such as hospitals, schools, homes, hotels, resorts, greenhouses, food processing plants,
warehouse, dairy and poultry farms, animal care facilities and disease control programs, house stables,
and much more.
Technical specification
|
Electrical Motor |
1200w(PS-ULV-003H); 800w(PS-ULV-004H)
220VAC/50Hz |
|
Fogging Nozzle |
Three counter-rotating vortex nozzle |
|
Particle Size |
5~20 micron VMD, adjustable |
|
Chemicals |
Handles both oil-and water-based chemical solutions
(Liquid viscosity and density affect particle size) |
|
Liquid Flow Rate in l/h |
0~36l/h, adjustable |
|
Tank Capacity in l |
4L(could choose the 8L solution tank) |
|
Dimensions in mm(L×W×H). |
300×200×470(PS-ULV-004H)
200×200×470(PS-ULV-003H) |
|
Weight in kg, empty |
2.9(PS-ULV-004H) 2.6(PS-ULV-003H) |
|
Dimensions in mm(L×W×H). (shipping data) |
490×225×285 |
|
Weight in kg, empty(shipping data) |
3.6(PS-ULV-004H) 3.3(PS-ULV-003H) |
