Features:
● Developed by the most up-to-date patented technology, mini size of ONLY 1 meter length. Flexible, easy to carry, convenient to operate in small space.
● Equipped with supercharged engine, it is easy to start and has high efficiency, stronger power and longer spraying distance. The smog can be easily distributed.
● Excellent and thin mist to be generated when mounted with High Efficent Spraying Tube.
● Having two spraying tubes which can spray both smoke and fog.
● Special designed for Auto Igniting, easy to start.
● More accurate, more innovative
● Easy to maintain.

Technical Specification:
Weight, empty in kg, approx. |
7.0 |
Dimensions in mm(L×W×H) |
1000×280×330 |
Weight, empty in kg, approx.(shipping data) |
11.5 |
Dimensions in mm(L×W×H)(shipping data) |
1000×350×360 |
Solution tank capacity in L |
6 |
Fuel tank capacity in L |
1.8 |
Fuel consumption in l/h, approx. |
1.6~1.8 |
Performance of combustion chamber in KW/HP |
Min.17 |
Maximum flow rate in l/h |
40 |
Flow rate with oil in l/h, approx. |
5~40 |
Energy |
2×1.5V batteries |
Spray fog distance in m |
10~20 |
Spray water distance in m |
7~9 |
Mist Diameter μm |
Max.30 |
Pressure in the solution tank in bar, approx. |
0.3~0.5 |
Pressure in the oil tank in bar, approx. |
0.3~0.4 |
Fuel Type |
90# purified gasoline |
Solution Type |
0# diesel oil or specialized carrier |
Scope of application:
Agriculture, forestry, orchards, greenhouses pest and disease control, sanitation and epidemic prevention, food processing and sterilization, pest control, fire drills, film shooting, etc.
|
