Features:
● Equiped with Swirl Injection Engine, High efficiency, Fuel saving, more powerful and longer spraying distance.
● Excellent and thin mist to be generated when mounted with High Efficent Spraying Tube.
● Having two spraying tubes which can spray both smoke and fog.
● Special designed for Auto Igniting, easy to start.
● More accurate, more innovative.
● Easy to maintain.
Technical Specification:
|
Weight, empty in kg, approx. |
8.0 |
|
Dimensions in mm(L×W×H) |
1345×280×330 |
|
Weight, empty in kg, approx.(shipping data) |
13.0 |
|
Dimensions in mm(L×W×H)(shipping data) |
1200×350×360 |
|
Solution tank capacity in L |
6 |
|
Fuel tank capacity in L |
1.8 |
|
Fuel consumption in l/h, approx. |
1.8~2.0 |
|
Performance of combustion chamber in KW/HP |
Min.19 |
|
Maximum flow rate in l/h |
60 |
|
Flow rate with oil in l/h, approx. |
5~60 |
|
Energy |
2×1.5V batteries |
|
Spray fog distance in m |
15~30 |
|
Spray water distance in m |
8~10 |
|
Mist Diameter μm |
Max.30 |
|
Pressure in the solution tank in bar, approx. |
0.3~0.4 |
|
Pressure in the oil tank in bar, approx. |
0.3~0.4 |
|
Fuel Type |
90# purified gasoline |
|
Solution Type |
0# diesel oil or specialized carrier |
Scope of application:
Indoor and outdoor sanitation and epidemic prevention, a large crop pest and disease control.
|
